Electrogrip 60mm 3 Meter GI Earthing Electrode

Send Inquiry

Request To Call Back

Electrogrip 60mm 3 Meter GI Earthing Electrode

Name: Electrogrip 60mm 3 Meter GI Earthing Electrode
Brand: ELAPP POWER PRIVATE LIMITED
Price: 3450 INR
Availability: InStock

Price 3450 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Electrogrip 60mm 3 Meter GI Earthing Electrode Specification

Tensile Strength
Approx. 300 N/mm²

Life Span
Up to 30 years (depending on soil condition)

Strength
High conductivity and corrosion resistance

Diameter
60 mm

Purity
99% pure GI

Product Type
GI Earthing Electrode

Material
Galvanized Iron (GI)

Application
Earthing protection for substations, industrial plants, commercial and residential electrical installations

Function
Electrical earthing and grounding

Shape
Cylindrical pipe

Surface Treating
Hot dip galvanized

Tolerance
± 2 mm

Dimension (L*W*H)
3000mm x 60mm x NA

Weight
Approximately 18-22 kg

Color
Silver/Galvanized

Earth Resistance Value
Less than 1 Ohm (when installed with backfill compound)

Inner Fill Material
Crystalline Conductive Compound

Connection Terminal
Pre-drilled holes for copper strip/cable termination

Packaging
Individually packed or bundled as per requirement

Corrosion Protection
Yes, full length galvanized

Outer Coating Thickness
> 100 microns

Installation Type
Direct driving into earth or pit burial

Length
3 Meter

Resistivity
< 1 Ohm-meter

Rod Type
Solid Pipe Type

Electrogrip 60mm 3 Meter GI Earthing Electrode Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Day

Delivery Time
24 Hours

About Electrogrip 60mm 3 Meter GI Earthing Electrode

Specification

Length Of Rod	3 Meter
Coating Thickness	Upto 80 Microns
Material	Galvanized Iron (GI)
Usage/Application	Maintenance Free Chemical Earthing
Model Name/Number	EGEE6003
Diameter	60mm
Packaging Type	Plastic Wrap
Terminal Hole	8mm
Terminal Size	50mm x 6mm
Certification	CPRI Certified
Service Life	10 Years
Brand	Electrogrip
Country of Origin	Made in India

Exceptional Durability and Corrosion Protection

With a comprehensive hot dip galvanized finish and a coating thickness exceeding 100 microns, the Electrogrip Earthing Electrode ensures long-lasting performance against rust and environmental degradation. Its robust build and high-grade materials enable it to maintain integrity up to 30 years, depending on soil conditions.

Superior Conductivity for Optimal Safety

Thanks to its pure GI material and crystalline conductive compound, this electrode achieves earth resistance values below 1 Ohm, helping maintain effective grounding. Reliable grounding helps protect people and equipment from electrical faults, ensuring the safe operation of electrical systems in various environments.

FAQ's of Electrogrip 60mm 3 Meter GI Earthing Electrode:

Q: How is the Electrogrip 60mm GI Earthing Electrode installed?

A: The electrode can be installed by either directly driving it into the earth or burying it in a pit. To achieve optimal earth resistance, it is recommended to use a suitable backfill compound during installation and ensure the pre-drilled terminal is securely connected to a copper strip or cable.

Q: What is the primary function of this earthing electrode?

A: Its main purpose is to safely dissipate electrical fault currents into the ground, providing effective earthing and protection for substations, industrial plants, commercial, and residential electrical installations.

Q: When should I choose this electrode over other earthing options?

A: Choose the Electrogrip 60mm GI Earthing Electrode when you require high conductivity, low earth resistance (less than 1 Ohm), exceptional corrosion resistance, and a long lifespan-making it suitable for harsh soil conditions and critical electrical infrastructures.

Q: Where is this electrode typically used?

A: It is widely used in substations, industrial facilities, commercial complexes, and residential buildings across India and internationally. Its versatility makes it suitable for both new installations and upgrades of existing earthing systems.

Q: What is the process of connecting cables to the electrode?

A: The electrode features pre-drilled holes at the terminal end, allowing direct and secure connection to copper strips or cables. This design ensures strong electrical contact and simplifies the installation process.

Q: What are the benefits of using a galvanized iron (GI) earthing electrode?

A: Using hot dip galvanized GI provides superior corrosion protection, high conductivity, and a lifespan of up to 30 years in favorable soil conditions. This translates to lower maintenance and enhanced safety in the long term.
